Reviewing Activity Clips

Find and play back the short clips that a kiosk saves when there is movement at the gate, so that you can review entry activity later.

When there is movement at the gate, a kiosk tablet saves a short clip. Community staff can play these clips later on the Activity clips tab, for example to see a vehicle that turned around before its entry. Residents do not see this tab.

Open the Activity clips tab

1. In the navigation menu, select Cameras.

2. Select the Activity clips tab.

The Cameras section shows the Activity clips tab when your community has a paired kiosk tablet or saved clips. If your community also uses the Eagle Eye camera integration, the section also has the Live, Analytics, LPR and APM tabs, and it opens on Live. Without Eagle Eye, the section opens on Activity clips.

The Activity clips tab on a computer, with clip cards under the Today and Yesterday headings. Two cards show more camera angles, and one card shows Cut short.

Find a clip

The tab opens on the clips of the last 7 days. The clips show under a heading for each day, for example Today, Yesterday or Oct 1. The newest clip is first.

  • To see other days, select Date range. Then select Today, Last 3 days, Last 7 days, Last 30 days or Custom range. A custom range can be up to 30 days long.
  • To see the clips of one gate, select Gate, then select the gate. The list shows the Brivo doors of your community.
  • On a phone, select Filters to open the two filters. Select an option, then select the button at the bottom, for example Show 9 clips.

Each filter that you apply shows as a chip above the clips. To remove one filter, remove its chip. To remove all of them, select Clear all. The page address keeps the filters, so a reload or a copied link shows the same clips.

If no clip matches, the tab shows No clips in this range. Select a longer date range to see older clips.

The size of the cards follows the List density choice in Account > Preferences: Comfortable shows larger cards, and Compact shows smaller cards. Smaller screens always show comfortable cards. Use the controls under the cards to go to the next page, or to show 24, 48 or 96 clips on each page.

Read the clip cards

Each card is one event at the gate. The card plays a short preview while it is on the screen. Under the preview, the card shows the time and the length of the event.

  • A chip such as +1 angle shows that more cameras of the kiosk saved a clip of the same event.
  • A Cut short chip shows that the recording stopped early, for example when the tablet lost power. The clip plays up to the last footage that MyWatchtower received.

Play a clip

Select a card to open the clip. The clip window shows the date and the time of the event, the gate and the length. The clip starts to play.

  • To play or pause the clip, select the play button or select the video.
  • To go to a different point in the clip, drag the bar under the video.
  • To change the speed, select the speed button. Each time you select it, the speed changes to the next value: 1×, 1.5×, 2× or 0.5×.
  • To make the video larger, select the full-screen button.
  • To see a different camera angle, select an angle above the video, for example Front or Left. If one camera saved more than one part, each part has its own button, for example Front · 1/2. The parts play one after the other.
  • To go to the previous or the next event, select the arrow buttons. The counter between the arrows shows the number of the event, for example 2 of 6.
  • To save the clip on your device, select the download button.
  • To close the window, select the close button.

You can also use the keyboard. Outside the video, the left and right arrow keys go to the previous or the next event. When the video has the focus, the Space key plays or pauses it, and the arrow keys go back or forward 5 seconds.

Clips on entry records

When a visitor makes an entry at a kiosk, the entry page can also show the clip of that visit. Open the entry from Community > Entries. The clip is under Captures. You see it only when your role has the Activity Clips permission.

How long clips stay

MyWatchtower keeps each clip for 30 days, and then deletes it. JEKA can set a different period for your community, from 1 to 365 days.

Permissions

The Activity clips permission controls access to the tab. This permission is separate from the Cameras permission, so a role can have access to clips and no access to camera feeds, or the other way around. By default, the Admin, Supervisor and Gate Attendant roles have the Activity Clips permission. If you do not see the tab, ask your community Admin to check your role.

For admins

Each kiosk tablet controls its own clips. On the tablet, the kiosk setup has an Activity clips step:

  • The Save clips on movement switch turns clips on or off for the kiosk.
  • Keep recording after movement stops sets how long a clip continues after the movement stops, from 2 to 60 seconds. New movement in that time stays in the same clip. The setting applies to each camera of the kiosk.
  • Each camera of the kiosk has its own switch and its own sensitivity setting.
  • Clip quality sets the resolution of each camera. It can also record a test clip and test the upload from the tablet.

Camera settings under Settings is for Eagle Eye cameras only. Activity Clips does not use it.

Need help?

If the clips of a gate do not show or do not play, use the Contact support form in the app. JEKA can then check the kiosk tablet.
